Hongfa HFB575A Block Machine

Automatic Block Machine HFB575A

The automatic block moulding machine HFB575A is our new design machine and controlled by the PLC. This hydraulic brick machine is considered to used with the middle and small factory. Contact us now to speak your requirements with an expert.

  • Powered by the hydraulic system to make excellent blocks

  • Controlled by PLC for easy operation and maintenance

  • High productivity, excellent quality, and strong durability

Get Free Quote >>

Automatic Block Making Machine HFB575A

The hydraform block machine HFB575A is composed of pallet conveyor, molding machine, block conveyor, hydraulic station, and electronic console. The block molding mainly by hydraulic, machinery as sideline, vibrate and press to finish molding blocks. Our machine is assembled with our own patent vibrating system and with high power and frequency.  It is our new design machine and controlled by the PLC. And this machine is considered to used with the middle and small factory and its features as follow:

  • Advanced Technology

Combining with German High-tech and Hongfa Technology to integrate the mechanic, electricity, hydraulic and high vibration work. This advanced cement solid block making HFB575A  is driven by hydraulic and popular by these aspects:

– Passing the strict quality inspection: CE/SGS/ISO9001:2000
– All the electrical and hydraulic parts are original imported or with China famous brand.
– Its characteristic is high efficient, easy-operated and easy-maintained.
– Moulds system is working synchronized and can ensure the block  products with same thickness and stable.

  • Excellent Design

The whole process of this brick making machine HFB575A is controlled by PLC and powered by the hydraulic system. Monitoring with the approach switch, machinery, electric, hydraulic and vibrating system work together to make pallets feeding, material feeding, vibrating, demoulding process work automatically. And its characteristic is high efficient, easy-operated and easy-maintained.

– Block molding mainly by hydraulic, machinery as sideline, vibrate and press to finish molding blocks. Our machine is assembled with our own patent vibrating system and with high power and frequency.

– All the electrical and hydraulic parts are original imported or with China famous brand. So this machine is stable and with less faults. Also it is can be used many years and easy to maintaining.

– Finished block products come out together then can be stacked efficient and cut off the power consumption and the labor.

  • Strong and Stable Structure

The host machine structure of the cement block laying machine is designed overall frame structure, use #12 U-bar welding together, compact structure, strong resistance to vibration.

  • Superior Hydraulic system

The mold of  the building brick making machine is accomplished by the mold cylinder, which was installed in the middle top of the host structure. The cylinder connects the up platform through the extension bar and transition connection, revising the height of up mold by adjusting the extension bar and transition connection when working.

  • Excellent Material Feeder System

This system is made up with hopper, feeding box, feeding platform and conveyor system.The material feeder just located on the below of the hopper and under the feeding platform.  And material feeder is powered with hydro-cylinder which supplied from the hydraulic station. When the down mould fall down onto the pallet, then material feeder move forward and starts to feeding material with vibrating. When testing the machine, the vibrating feeding time can be adjusted according to the material and the request of the products.

  • Special Vibrating and Moulding System

The molding system of the automatic cement block laying machine HFB575A is made up with the frame, vibrating platform, moulds and synchronizing mechanism system. The vibrating system is working with 2 motors. The motors supply the power to the 2 sets eccentric shaft with triangle belt. When finish feeding the material, upper mould fall down onto the down mould, then the vibration and press system work together to mold the products.

  • Flexible Block Production Line

It is composed of pallet conveyor, molding machine, block conveyor, hydraulic station, and electronic console for the configuration of the cement block making machine HFB575A. It can combine the mixer, belt conveyor and block stacker to make a simple block production line.

  • Achieve Scrutiny and Smart Controlling

The control system is equipped with complete logic control, production program, malfunction diagnosis system and remote control function. Warning signal is propitious to eliminate the fault, so it only needs a trained person for operation rather than a professional one.

  • High Quality Blocks Produced

This brick machine can use flyash, slag, gangue and other kind industrial residue then with sand, water, crushed stone, cement all kind material to make all kind hollow block, paver brick, solid bricks just changing the moulds. This brick machine can use fly ash, slag, gangue and other kind industrial residue then with sand, water, crushed stone, cement all kind material to make all kind hollow block, paver brick, solid bricks just changing the moulds.

  • Available for Various Raw Materials

The raw materials to make block or brick with this cement building block making machine are: crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes.

HFB575A Block Machine Technical Parameters

Hongfa Brick Making Machine
HFB575A
Technical ParameterDetailed Data
Overall Dimension7100×1600×2610(mm)
Rated Pressure16MPa
Main Vibration FormPlatform Vibration
Cycle Time15 seconds
Vibration100KN
Vibrating Frequency2800-4500
rolls/minute
Motors Power27.5KW
Pallet Size1020*570(mm)
Weight4443KG

The Finished Block Products Capacity

The Finished Block Products

Specifications

Block TypeMold

Cycle

Pcs

/Mold

Pcs

/8hrs

Hollow Block
400*200*200mm
15s47600
Solid Block
240*115*53mm
15s2853700
Paving Brick
220*110*50mm
15s1623000

Applied Block Samples Photo

concrete block size sample1
